Model: LD-500YS
Lane Number: 1~4 (Track)
Sealing type: Irregular shape bag
Film width&thickness: Max.500mm; 0.07--0.10mm
20-30 cycle/min
Model: LD-500YS
Lane Number: 1~4 (Track)
Sealing type: Irregular shape bag
Film width&thickness: Max.500mm; 0.07--0.10mm
20-30 cycle/min
● High speed multilane irregular shape sachet packing machine suitable for viscous liquid, coconut oil, gel, honey, laundry detergent,yogurt,detergent,soya milk,stuffing, sauces,beverage, shampoo,reagent, drinking water,juice,pesticide emulsion, dyes, pigments and medium viscosity of the paste objects.
Packaging Material:
sauce
ketchup
butter
ketchup
paste
Jam
Bag Style:
Irregular shape bag
Irregular shape bag
Irregular shape bag
Irregular shape bag
Irregular shape bag
Irregular shape bag
● English and Chinese screen display, operation is sample.
● PLC computer system, function is more stable, adjustment any parameters not need stop machine.
● It can stock ten groups of parameters, simple to change variety.
● Servo motor drawing film, positing accurately.
● Temperature independent control system, precision get to 1 degree.
● Horizontal, vertical temperature control, suitable for various of mix film, PE film bag material etc.
● Model: LD-500YS
● Track number: 1~4 (Track)
● Capacity: 20-30 cycle/min
● Sachet size: L: 50-170mm, W:40-230mm
● Sealing type: Irregular shape bag
● Film width&thickness: Max.500mm; 0.07--0.10mm
● Filling method: 1.Piston pump, 2.Peristaltic pump
● Power Supply: 220V/380V 50HZ, 5.0KW
● Air consumption: 0.8Mpa,0.8m3/min
● Dimension&weight: 2600*1350*2350mm, 800kg
● We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
After receiving your inquiry, We will send you the quotation as soon as possible.
