Model: LD-320AB/ 380AB
Suitable for the automatic packaging of granular food, and can automatically put the desiccant in the packaging bag, the such as nuts, snacks, beans, peanut, cashew packing etc.
Film Roll Diameter: Max.320mm
Film Width: 120-380mm
35-70bag/min
Model: LD-320AB/ 380AB
Suitable for the automatic packaging of granular food, and can automatically put the desiccant in the packaging bag, the such as nuts, snacks, beans, peanut, cashew packing etc.
Film Roll Diameter: Max.320mm
Film Width: 120-380mm
35-70bag/min
● Suitable for the automatic packaging of granular food, and can automatically put the desiccant in the packaging bag, the such as nuts, snacks, beans, peanut, cashew packing etc.
● High precision structure for simple and easy operation and repair.
● CPU simgle chip ,step motorl,easy and accurate to set the bag length.
● It's owns simple circuitry and outstanding function.
● The machine completes the whole procedure of filling,bagging,date printing,charging(exhausting) automatically.
| Model | LD-320AB | LD-380AB |
| Film width | 120-320mm | 180-380mm |
| Bag length | 50-200mm | 60-280mm |
| Bag width | 50-150mm | 60-180mm |
| Diameter of film roll | Max.300mm | Max.320mm |
| Packing speed | 35-70bag/min | |
| Measuring range | 50-500ml | 50-750ml |
| Film thickness | 0.04-0.07mm | |
| Power | 220V 50/60Hz 2.2KW | 220V 50/60Hz 2.5KW |
| Machine size(L*W*H) | 970*680*1950mm | 1100*800*2150mm |
| Machine weight | About 300kg | About 450kg |
● Date Coder
● Hole Punching Device(Pinhole, Round hole, the butterfly hole)
● Linking bag control device
● Air-filling Device
● Air Exhaust Device
● Tear Notch Device
