Model: LD-960Y
Application:
Applicable industry: Suitable for liquid products containing fine particles such as mayonnaise, chili sauce, bean paste, instant noodle sauce, ketchup, paste, honey, cream, milk, butter, water, oil, vinegar, liquid seasoning, shampoo, jelly, etc.
Max.40 cycle/min
Model: LD-960Y
Application:
Applicable industry: Suitable for liquid products containing fine particles such as mayonnaise, chili sauce, bean paste, instant noodle sauce, ketchup, paste, honey, cream, milk, butter, water, oil, vinegar, liquid seasoning, shampoo, jelly, etc.
Max.40 cycle/min
Application:
Suitable for mayonnaise, sauces, ketchup, egg white, jam, chili sauce, lotus seed paste, bean paste and other food stuffing as well as drinks of large bulk.
Kindly Reminder:
Please tell us the following information when you send us an inquiry. Based on your message, we will suggest the optimum solution to you for reference. Thank you.
1. Bag dimension
2. Bag weight
3. Your product
4. Bag shape
5. Bag material
● 1. High production efficiency, the speed of 10 rows can reach 200-300 packs per minute, which improves the production capacity and saves manpower.
● 2. With a stirring device, it is suitable for sticky materials, such as chili sauce, chocolate sauce, mayonnaise, etc.
● 3. Ultraviolet disinfection, in line with food hygiene, ensures safe production.
● 4. Multi lanes machines can produce multi lanes bags at the same time.
● 5. Machine main function: automatic split film at the right position, liquid measuring, and filling, multi lanes bag form fill seal, cutting, sensor tracking, counting capacity.
● 6. Other functions: Emergency stop, set capacity to auto stop machine, count capacity and Zero the count, ready bag output, manual test machine each step, etc.
● 7. The stainless steel contact part and the machine's outer shell, have high features for a liquid running environment.
● 8. High-precision photocell sensor for auto-tracking the eye mark printing on the film roll, so cut each bag at a precise position.
● 9. PLC controller, high function and control the whole machine's work steps.
| Model | LD-480Y | LD-720Y | LD-960Y |
| Track Number | 4~6 Track | 4~10 Track | 4~12 Track |
| Filling Method | 1.Piston pump; 2.Peristaltic Pump | ||
| Capacity | Max.40 cycle/min | ||
| Sachet Size | L:45--120mm; W:35-60mm | L:45--120mm; W:35-90mm | L:45--120mm; W:35-120mm |
| Film Width & Thickness | Max.480mm;0.07-0.1mm | Max.720mm;0.07-0.1mm | Max.960mm;0.07-0.1mm |
| Sealing Type | 3/4 sides sealing | 3/4 sides sealing | 3/4 sides sealing |
| Cutting Type | 1. Straight Cutting; 2. Zig Zag Cutting; 3. Continuous Cutting | ||
| Air & Power | 0.8 mpa 0.8m³/min; 2.8kw | 0.8 mpa 0.8m³/min; 4.1kw | 0.8 mpa 0.8m³/min; 5.5kw |
| DIM & WT | 950*1470*1750mm; 300kg | 1153*1654*1750mm; 400kg | 1415*1686*2130mm; 500kg |
● Sealing Type: 4 sides sealing; 3 sides sealing.
● Cutting Type:
Straight Cutting;
Zig Zag Cutting;
Continuous Cutting.
