Model: LD-960Y
Application:
This machine is applicable for dosing liquid or semi-liquid and sealing in form of 3/ 4 side sealed sachet, include the sachet forming, product dosing, filling and sachet sealing processes, with single cutting or string sachet cutting.
35 cycle/ min
Model: LD-960Y
Application:
This machine is applicable for dosing liquid or semi-liquid and sealing in form of 3/ 4 side sealed sachet, include the sachet forming, product dosing, filling and sachet sealing processes, with single cutting or string sachet cutting.
35 cycle/ min
●Appliacation: This machine suitable for foods, chemicals, and daily-chemicals industries’ fluid and cream packing such as shampoo, edible oil, cream and emulsion, fruit juice, fruit sauce, and butter, etc.
●Kindly Reminder: We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
●Multi lanes machine can produce multi lanes bags at same time.
●Machine main function: automatic split film at right position, liquid measuring and filling, multi lanes bag form fill seal, cutting, sensor tracking, counting capacity.
●Other function: Emergency stop, set capacity to auto stop machine, count capacity and Zero the count, ready bag output, manual test machine each step etc.
●Stainless steel contact part and the machine outer shell, high feature for liquid running environment.
●High precision photocell sensor for auto tracking the eye mark printing on the film roll, so cut each bag at precisely position.
●PLC controller, high function and control the whole machine' s work steps.
| Type | LD-DL-024 |
| Bag length | 30--120mm(L) |
| Bag width | 10---50mm(W) |
| Max width of roll film | 440mm |
| Packing speed | 30—60 bag /min / lane |
| Air consumption | 0.65mpa |
| Gas consumption | 0.3m3/min |
| Power voltage | 380VAC/220VAC/50Hz |
| Power | 2.5 KW |
| Dimension | 1000mm(L)*1000mm(W) *2000mm (H) |
| Weight | 420 kg |
● Sealing Type: 4 sides sealing; 3 sides sealing.
● Cutting Type:
Straight Cutting;
Zig Zag Cutting;
Continuous Cutting.
