Automatic Frozen Food Horizontal Flow Wrap Machine With Tray

Model: LP-250X/ 350X/ 450X/ 600X/ 700X/ 800X/ 900X

Application: Suitable for packing soft, sticky or multi pack products such as towel, tissue, noodles, egg rolls, sausages, ice lolly, ice cream bar, soft candy, cutlery, vegetables, etc.

Speed:

20-230 bags/min

Bag Size:

L: 65-700mm

W: 30-400mm

Automatic Frozen Food Horizontal Flow Wrap Machine With Tray

Model: LP-250X/ 350X/ 450X/ 600X/ 700X/ 800X/ 900X

Application: Suitable for packing soft, sticky or multi pack products such as towel, tissue, noodles, egg rolls, sausages, ice lolly, ice cream bar, soft candy, cutlery, vegetables, etc.

Speed:

20-230 bags/min

Bag Size:

L: 65-700mm

W: 30-400mm

 Application: suitable for packaging various kinds of regular objects like frozen meat, frozen fish, frozen seafood, chicken, beef, noodles, moon-cakes, drugs, daily applications, industrial parts,paper boxes,tray etc.

 Kindly Reminder: We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.


 Three servo motor control, Bag length can be set and cut in one step,saving time and film.

 Interface features easy and quick setting and operation

 Self failure diagnosis, clear failure display

 High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.

 Temperature independent PID control, more suitable for packaging different materials

 Positioned stop function, without sticking knife or wasting film.

 Simple driving system, reliable working, convenient maintenance.

 All control is realized through software,easy for function adjusting and technical upgrade.

ModelLP-350LP-400LP-450LP-600LP-700
Film WidthMax.350mmMax.400mmMax.450mmMax.600mmMax.700mm
Bag Length65-330mm150-400mm150-450mm160-500mm180-600mm
Bag Width50-160mm50-180mm50-180mm100-280mm100-330mm
Products HighMax.60mmMax.65mmMax.75mmMax.110mmMax.110mm
Film Roll DiameterMax.320mmMax.320mmMax.320mmMax.320mmMax.320mm
Packing Speed40-180bag/min30-150bag/min30-150bag/min20-150bag/min20-130bag/min
Power220V 50/60Hz220V 50/60Hz220V 50/60Hz220V 50/60Hz220V 50/60Hz
2.6KW2.8KW2.8KW2.8KW2.8KW
Machine Size4030*770*14204030*770*14204030*820*14204030*970*15004030*1070*1500
(L*W*H)mm
Machine WeightAbout 580kgAbout 600kgAbout 650kgAbout 680kgAbout 720kg
Optional Devices1.Lateral feed device, 2.Straight feed device, 3.Belt material conveyor,
4.End sealing auxiliary conveyor, 5.Auxiliary material feeding device, 6.Materia cut prevent device,
7.Perforating device, 8.Angle folding device, 9.Date Printer, 10.Labelling machine

 1.Belt material conveyor

 2.End sealing drag chain

 3.Auxiliary material feeding device

 4.Material cut prevent device

 5.Perforating device

 6.Angle folding device

 7.Date printer

 8.Labeling machine

 9.Thermal transfer code printer

 10.Air charging system

 11.Cutting stop

 12.Prevent empty package.
