Model: LDB-600
Sealing Type: Straight grain, pitch is 1mm(Optional reticulate)
Bag diameter: Φ380-Φ600mm(customizable)
Body Dimension: 1780*1250*1750mm
Yield: 10-15Bag/min
10-15 bag/min
Model: LDB-600
Sealing Type: Straight grain, pitch is 1mm(Optional reticulate)
Bag diameter: Φ380-Φ600mm(customizable)
Body Dimension: 1780*1250*1750mm
Yield: 10-15Bag/min
10-15 bag/min
Application:
● Typically weighing and packing machine is suitable for granules, nuts and pulses, wheat flour, flour, tea and coffee, confectionery, pets foods, bird foods, dog foods, cat foods, beans, grain, rice, sesame, sugar, salt, seeds, food additives, granola, muesli, fertilizer, berries, tomato chips, chocolate nuts, fodder, tablet, pepper etc.
Kindly Reminder
● We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Examples:
● Machine is specially developed for all kinds of composite composite pre-made bags.
● PLC & HMI Control, Easy for parameter setting and troubleshooting.
● Food-grade SUS304 contact surfaces.
● Intelligent temperature controlling configuration, ensure the artistic and neat sealing.
● Pouch saving design, no completely opened pouch, no filling and sealing.
● Automatic operation control, easy to adjust and operate.
● PLC controlled pouch loading - open - fill - seal - output.
| Model | LDB-600 |
| Premade Pouch Type | standup premade pouch, reseal-able premade pouch, flat bottom premade pouch, 3-side seal pouch, zipper pouch, zip-lock pouch, top zip pouch, heat seal pouch, kraft window-open paper pouch |
| Premade Pouch Size | W250 ~ 500mm X L380 ~ 600mm |
| Packing Speed | 10 ~ 15bags/min |
| Power Supply | 220V/50Hz or 60Hz, Single Phase 1KW |
| Air Pressure | 7.0CFM@80 PSI |
| Operation Panel | 7.0" User's touch screen |
| Electronic | Mitsubishi PLC / Omron Temperature Controller / Omron Power Switch / Schneider Breaker |
| Pneumatic | Pneumatics component Airtac from Taiwan; PIAB Vacuum generator/SMC Vacuum Fliter |
| Options | Auto Zipper open device, SMC Pneumatic Parts, Product Settler, Gasflush and vacuum function, Take Away Conveyors, Filling devices, Ribbon Stamp Printer |
● This powder filling system is driven by a servo motor to ensure high filling accuracy. It is controlled by PLC, man-machine interface and easy to operate. The filling volume can be changed by replacing the screw gauge, and the measuring range is wide.
