Model: LD-720AS
Application: It is suitable for quantitative packaging of powdery and micro-powdery materials, such as: detergent powder, flour, milk powder, pesticide, veterinary medicine, dye, chemical agent, food seasoning, additive, enzyme preparation and so on.
5-60bag/min
Model: LD-720AS
Application: It is suitable for quantitative packaging of powdery and micro-powdery materials, such as: detergent powder, flour, milk powder, pesticide, veterinary medicine, dye, chemical agent, food seasoning, additive, enzyme preparation and so on.
5-60bag/min
● Application:
It is suitable for quantitative packaging of powdery and micro-powdery materials, such as: detergent powder, flour, milk powder, pesticide, veterinary medicine, dye, chemical agent, food seasoning, additive, enzyme preparation and so on.
● Kindly Reminder: We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
● Chinese or English display(Language can be set according to customer requirements).
● Imported PLC control system, colorful touch screen, can clearly shows working state and operation indicator,easy to operate,intuitionistic and efficient.
● New high set according to modular control system.
● Amplitude of automatic adjustment function, debugging more convenient.
● Can weigh a variety of different materials at the same time, the realization of mixed material package.
● According to the production situation can directly modify the parameters in the running, easy operation.
● Adopts stepless vibration machine feed system, make the material more evenly, weighing range greater all adopt the stainless steel materials, clean health.
● With a pneumatic door opener, and can realize the vibration feeding machine will be automatically closed.
● And material contact parts (storage hopper, hopper, vibration plate, weighing hopper, etc.) are to realize fast disassembly, particularly convenient clean.
| Type | LD-420 | LD-520 | LD-620 | LD-720 |
| Film width | Max.420mm | Max.520mm | 150-Max.620mm | 150-Max.720mm |
| Bag length | 80-300mm | 60-400mm | 60-450mm | 60-500mm |
| Bag width | 60-200mm | 100-250mm | 65-300mm | 65-350mm |
| Film roll diameter | Max.600mm | Max.600mm | Max.600mm | Max.600mm |
| Packing speed | 5-60bag/min | 5-40bag/min | 5-35bag/min | 5-30bag/min |
| Making-bag volume | 1000ml | 2000ml | 3000ml | 5000ml |
| Film thickness | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm |  0.04-0.12mm |
| Power Supply | 220V,50/60Hz,3KW | 220V,50/60Hz,3KW | 220V,50/60Hz,3.2KW | 220V,50/60Hz, 3.5KW |
| Machine size(L*W*H) | (L)1217X(W)1015X(H)1343mm | (L)1488X(W)1080X(H)1490mm | (L)1488X(W)1180X(H)1550mm | (L)1780X(W)1350X(H)2050mm |
| Remarks | Optional air filling device/ (Optional gusseting device) | |||
| Film material | BOPP/CPP, BOPP/VMCPP, BOPP/PE, PET/VMPET/PE, PET/AL/PE, PET/PET ETC. | |||
1. LD series machine;
2. Z type conveyor;
3. Finished product conveyor;
4. Linear electronic scale.
After receiving your inquiry, We will send you the quotation as soon as possible.
