Model: LD-210SP
Pouch Type: All type of heat sealable preformed side seal bags, gusseted bags, block bottom bags,zip-lock recloseable bags, stand-up pouch with or without spout etc.
Filling Volume: 20-1000g
Packaging Accuracy:Error≤±1
20-50bag/min
Model: LD-210SP
Pouch Type: All type of heat sealable preformed side seal bags, gusseted bags, block bottom bags,zip-lock recloseable bags, stand-up pouch with or without spout etc.
Filling Volume: 20-1000g
Packaging Accuracy:Error≤±1
20-50bag/min
● Application: Automatic horizontal form fill seal machine, It is suitable to packaging small grain with good uniformity, such as candy, beans, oatmeal, sugar, salt, seeds, rice, sesame, milk powder coffee, etc
● Function: Flat Pouch, Doy pack, Zipper Pouch, Premade Pouch, Stand up Pouch.
● Kindly Reminder: We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
● The machine completes the whole procedure of filling,measuring,bagging,date printing,charging(exhausting),produt out-putting automatically.
● High precision,high efficiency without crash the materials.
● New design with perfect fashion, more reasonable structure, more advanced technology.
● Imported PLC control system, colorful touch screen, easy operation, intuitionistic and efficient.
● Standard positioning with imported servo film transporting system and mark sensor, superexcellent capability for complete machine, perfect packaging.
● With auto warning protection function to minimize loss.
● Various kinds of bag, it could provide the pillow bag, angle fold bag, hang hole bag, link bag, etc.
● Automatic correct funtion, save time, labor and film, the operation more intelligent.
Model | LD-160SP |
Packing Speed | 20-50 bag/min |
Total power | 380V,2.5KW,60Hz (Host) |
Package dimensions | 80-160mm*110-230mm (Bag width * bag length) |
Total Weight | 800KG |
Packing capacity | 20g-500g |
Air consumption | 0.7㎥/min |
Bag type | All type of heat sealable preformed side seal bags, gusseted bags, block bottom bags,zip-lock recloseable bags, stand-up pouch with or without spout etc. |
● Work flow: The operator pours the materials into the vibrating plate, and configures as many vibrating plates as there are as many materials in a bag. The vibrating plate transports the materials to the conveyor belt, and transports the materials to the bag through the Z-type loader. Then, a series of links such as blanking, filling, coding, and sealing are carried out to complete the packaging process.
