Model: LDS-320L-4 /380L-4
Suitable for 4 side sealing sachet of conventional liquids such as shampoo, sauces, seasoning, ketchup, honey, vitamin water, juice drinks, oil, water, etc.
Film Roll Diameter: Max.380mm
Film Width: 120-380mm
35-70bag/min
Model: LDS-320L-4 /380L-4
Suitable for 4 side sealing sachet of conventional liquids such as shampoo, sauces, seasoning, ketchup, honey, vitamin water, juice drinks, oil, water, etc.
Film Roll Diameter: Max.380mm
Film Width: 120-380mm
35-70bag/min
● Suitable for 4 side sealing sachet of conventional liquids such as shampoo, sauces, seasoning, ketchup, honey, vitamin water, juice drinks, oil, water, etc.
● High precision structure for simple and easy operation and repair.
● PLC touch screen,step motor control,easy and accurate to set the bag length.
● It's owns simple circuitry and outstanding function.
● The machine completes the whole procedure of filling,bagging,date printing.charging(exhausting) automatic.
● Optional device: 1. Date Coder; 2. Hole Punching Device(Pinhole, Round hole, the butterfly hole); 3.Linking bag control device; 4. Air-filling Device; 5. Air Exhaust Device; 6.Tear Notch Device.
| Model | LDS-320L-4 | LDS-380L-4 |
| Film width | 120-320mm | 180-380mm |
| Bag length | 50-200mm | 60-280mm |
| Bag width | 50-150mm | 60-180mm |
| Diameter of film roll | Max.300mm | Max.320mm |
| Packing speed | 35-70bag/min | |
| Measuring range | 50-500ml | 50-750ml |
| Film thickness | 0.04-0.07mm | |
| Power | 220V 50/60Hz 2.2KW | 220V 50/60Hz 2.5KW |
| Machine size(L*W*H) | 970*680*1950mm | 1100*800*2150mm |
| Machine weight | About 300kg | About 450kg |
● Date Coder
● Hole Punching Device(Pinhole, Round hole, the butterfly hole)
● Linking bag control device
● Air-filling Device
● Air Exhaust Device
● Tear Notch Device
