Model: LD-8200
Filling Weight: 10~3000g
Bag Size: L: 120~550 mm, W: 80~400 mm
Yield: 30~50 Bags/min
30~50 bags/min
Customizable
Application:
Suitable for packing fine dry powder materials, such as milk powder, spices powder, coffee powder, corn flour, laundry powder, coconut powder, fruit powder, collagen protein powder, cocoa powder, chili powder, etc. It integrates metering, bagging, packing, sealing, date printing, and counting into one.
Kindly Reminder:
We can customize the suitable one for you according to your requirements.
Just Tell us: Weight or Bag Size required.
● English and Chinese screen display, support multi-language customization. the operation is easy and simple.
● PLC computer control system, more stable performance, can be adjusted any parameters not need to stop the machine.
● It can stock ten group parameters, simple to change variety.
● Independent temperature control system, precision can reach ±1℃.
● Can automatically finish product weighing, filling, packing, sealing, and printing date in one.
● Quiet work circumstances quiet, low noise.
Model | LD-8200 |
Bag Size | L: 120~550 mm W: 80~400 mm |
Filling Range | 10~3000g |
Packing Speed | 30~50 bags/min |
Air Consmption | ≤ 0.6m³/min |
Machine Voltage | 220V/380V , 50/60Hz |
Total Power | 2.8 KW |
Machine Size | 2450*1880*1900 mm |
Machine Weight | 750 KG |
● This powder filling system is driven by a servo motor to ensure high filling accuracy. It is controlled by PLC, man-machine interface and easy to operate. The filling volume can be changed by replacing the screw gauge, and the measuring range is wide.
