Model: LD-BK-560G-6
Application: 6 lane granule stick packing machine, it is suitable for many kinds of fine granule products, such as sugar, salt, small grains, coffee, seeds, spice, washing powderetc etc.
Max.35 cycle/min
Model: LD-BK-560G-6
Application: 6 lane granule stick packing machine, it is suitable for many kinds of fine granule products, such as sugar, salt, small grains, coffee, seeds, spice, washing powderetc etc.
Max.35 cycle/min
● Application: 6 lane granule 3/4 sealing sachet packing machine, Suitable for many kinds of fine granule products, such as sugar, salt, small grains, coffee, seeds, spice, washing powderetc etc.
● Kindly Reminder: We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
● Multi lanes machine can produce multi lanes bags at same time.
● Machine main function: automatic split film at right position, liquid measuring and filling, multi lanes bag form fill seal, cutting, sensor tracking, counting capacity.
● Other function: Emergency stop, set capacity to auto stop machine, count capacity and Zero the count, ready bag output, manual test machine each step etc.
● Stainless steel contact part and the machine outer shell, high feature for liquid running environment.
● High precision photocell sensor for auto tracking the eye mark printing on the film roll, so cut each bag at precisely position.
● PLC controller, high function and control the whole machine’s work steps.
| Model | LDBK-280 | LDBK-560 |
| Lane number | 4-6 Line | 8-12 Line |
| Filling Method | 1.Volumetric cup; 2. Weigher | |
| Capacity | Max.35 cycle/ min | |
| Sachat Size | L:50-180mm; W:17-30mm | L:50-180mm; W:17-30mm |
| Film weidth & Thickness | Max.280mm, 0.07-0.10mm | Max.560mm, 0.07-0.10mm |
| Sealing type | Back sealing/Stick bag | Back sealing/Stick bag |
| Cutting type | 1.Straight cutting; 2.Zig zag cutting; 3.Round cutting; 4.Irregular | |
| Air & Powder | 0.8Mpa 0.8m3/min; 3.5kw | 0.8Mpa 0.8m3/min; 5.5kw |
| Dimension & weight | 1385*918*2005mm;350kg | 1685*1300*2005mm;550kg |
● Sealing type: Back sealing/Stick bag;
● Cutting type:
1.Straight cutting;
2.Zig zag cutting;
3.Round cutting;
4.Irregular
